hAP ac lite Torre
El hAP ac lite es un punto de acceso dual concurrente, que proporciona cobertura Wifi para frecuencias de 2,4 GHz y 5 GHz al mismo tiempo.
La unidad está equipada con una CPU de 650 MHz, 64 MB RAM, cinco puertos 10/100Mbps Ethernet (salida PoE en el puerto #5), de doble cadena MIMO 802.11b/g/n inalámbrica de 2.4 GHz, de cadena sencilla SISO 802.11ac 5 GHz inalámbrico, puerto USB para 3G / módem 4G y una licencia RouterOS L4.
La nueva caja del diseño universal permite que la unidad sea colocada de forma horizontal (escritorio) o vertical (caso de la torre). Muro anclado se proporciona kit de montaje.
*.
Características principales de RouterOS
| Details | |
|---|---|
| Product code | RB952Ui-5ac2nD-TC |
| CPU nominal frequency | 650 MHz |
| CPU core count | 1 |
| Size of RAM | 64 MB |
| 10/100 Ethernet ports | 5 |
| Wireless standards | 802.11a/n/ac |
| Wireless chip model | QCA-9887 |
| Secondary wireless standards | 802.11b/g/n |
| Secondary wireless chip model | QCA9531 |
| Number of USB ports | 1 |
| Power Jack | 1 |
| PoE out | Yes |
| Supported input voltage | 10 V – 30 V |
| PoE in | Yes |
| Dimensions | 34 x 119 x 98mm |
| Operating System | RouterOS |
| License level | 4 |
| Antenna gain | 2 |
| CPU | QCA9531 |
| Max Power consumption | 8W |
| USB slot type | USB type A |
| USB Power Reset | Yes |
| Number of chains | 1 |
| Storage type | FLASH |
| Storage size | 16 MB |
Wireless specifications
| 5 GHz | |||
|---|---|---|---|
| Transmit power (dBm) | Receive Sensitivity | Transmit power (mW) | |
| 6MBit/s | 23 | -93 | 200 |
| 54MBit/s | 20 | -75 | 100 |
| MCS0 | 23 | -93 | 200 |
| MCS7 | 19 | -71 | 79 |
| MCS9 | 16 | -63 | 40 |
| 2.4 GHz | |||
|---|---|---|---|
| Transmit power (dBm) | Receive Sensitivity | Transmit power (mW) | |
| 1MBit/s | 22 | -96 | 158 |
| 11MBit/s | 22 | -89 | 158 |
| 6MBit/s | 20 | -93 | 100 |
| 54MBit/s | 18 | -74 | 63 |
| MCS0 | 20 | -93 | 100 |
| MCS7 | 16 | -71 | 40 |
Included parts
Ethernet test results
| RB952Ui-5ac2nD-TC | QCA9531 (650Mhz) 100M all port test | ||||||
| Mode | Configuration | 1518 byte | 512 byte | 64 byte | |||
| kpps | Mbps | kpps | Mbps | kpps | Mbps | ||
| Bridging | none (fast path) | 40.6 | 493.0 | 117.4 | 480.9 | 217.0 | 111.1 |
| Bridging | 25 bridge filter rules | 40.6 | 493.0 | 70.1 | 287.1 | 70.9 | 36.3 |
| Routing | none (fast path) | 40.6 | 493.0 | 117.4 | 480.9 | 200.8 | 102.8 |
| Routing | 25 simple queues | 40.6 | 493.0 | 79.6 | 326.0 | 90.8 | 46.5 |
| Routing | 25 ip filter rules | 40.6 | 493.0 | 42.2 | 172.8 | 43.2 | 22.1 |
