Key Specification
- Number of 1 Gbps SFP Ports: 2
- Number of 10/100/1000BASE-T Ports: 8
- Layer: Layer 2
- Switching Capacity: 20 Gbps
- Forwarding Rate: 14.8 Mpps
- MAC Address Table Size: 8000
- Max. Number of VLANs: 16
- Dimensions (W x D x H): 50 mm x 155 mm x 130 mm (1.97 in. x 6.10 in. x 5.12 in.)
- Net Weight: 0.79 kg (1.74 lbs)
- Mean Time Between Failure (MTBF): > 200,000 hours
- Warranty: 5 years
- Port Surge Protection: Common mode: 6 kv
- Certification: CE
Espesificaciones de Energia
Switch DC input:
● Rated voltage range: 46 V DC to 57 V DC
● Rated current range: 7 A
● Consumo MIN. 12 W (sin carga PoE)
● Consumo MAX. 312 W (con carga PoE)
Fuente RG-NIS-PA240-54 (AC input):
● Rated input voltage: 100 V AC to 240 V AC, 50/60 Hz
● Maximum input voltage: 90 V AC to 264 V AC, 47 Hz to 63 Hz
● Rated input current: 3.5 A Output：
● Rated output voltage: 54 V DC
● Maximum output current: 4.4 A
Fuente RG-NIS-PA120-54 (AC input):
● Rated input voltage: 100 V AC to 240 V AC, 50/60 Hz
● Maximum input voltage: 85 V AC to 264 V AC, 47 Hz to 63 Hz
● Rated input current: 1.5 A Output：
● Rated output voltage: 54 V DC
● Maximum output current: 2.5 A
Especificaciones Técnicas
- Industrial para temperaturas extremas
- Protección contra descargas eléctricas
- 1 Puerto PoE++ y 7 Puertos PoE+
- 2 Puertos SFP para conexión de fibra óptica
- Capacidad de conmutación de 20 Gbps
- Diseño compacto y resistente para entornos industriales
